Product Description

Contact for Price

Technical Specifications:

Hardware Interface :

  • Hardware Overview:
  • 1 × PoE port
  • 1 × RJ45 port
  • 6 × RS232 port
  • 2 × RS422/485 port
  • 2 × IR out port
  • 4 × Relay port
  • 4 × GPIO in/out
  • 1 × IR Learning port
  • 1 × MGMT port
  • 1× 12V/2A power supply port
  • Analog Inputs: 12bit A/D, 0 to 24VDC
  • Digital Outputs: 3.3V, 3.3mA
  • Pin Configurations: Pin1,2,3,4=GPIO In/Out, Pin5=Gnd, Pin6=12VDC

IR Learning:

  • Carrier Frequency: Below 38kHz
  • Capture Distance: Below 4m from the front panel

Power Supply:

  • Power Consumption:
  • Average: 2.5W
  • Peak: 3.3W
  • Standby: 1.7W

Installation:

  • Installation Method:
  • Rack installation
  • Flat installation
  • Environmental Factors:
  • Operating humidity: 1095%
  • Operating temperature: -10+45°C
  • Storage temperature: -30~70°C

Dimensions and Weight (W × D × H):

  • Giftbox size: 259 × 193 × 124 mm
  • Carton size: 635 × 265 × 209 mm
  • Dimensions: 216 × 160 × 36.7 mm
  • G.W/CTN: 9.133kg
  • N.W/CTN: 8.485kg
  • Weight: 1.07kg

What's Included:

  • 1 × CT300
  • 1 × 3m Cat5 cable
  • 1 × 1.0m USB 3.0 Type-C to Type-A Cable (for management port)
  • 1 × Power adapter (12V / 2A)
  • 2 × Infrared Emitter (for IR output control)
  • Male phoenix connectors for control connection
  • 1 × Mounting Kit (for wall, flat surface, or rack installation).
  • Includes mounting ears, rack connection piece, and screws
  • 1 × Quick start guide
Sku: CT300
Vendor: Yealink
